VEHICLE SPECIFICATIONS:
Built in 2006 by GPV, a Military Vehicle Contractor
Seating Capacity is (3) in the Cab
GVWR is 26,989 Kilograms (59,500 Pounds)
Front / Center / Rear Axels are rated at 8,996 Kilograms (19,833 Pounds) each
Truck Body Ground Clearance is adjustable 0.07 – 0.54 Meters (3 – 21 Inches)
Maximum Speed on Hard Surface is 113 Kilometers (70 miles per hour)
Fuel Capacity is 189 Liters (50 Gallons)
Estimated Range on Hard Surface is 378 Kilometers (235 miles)
Fording Water Depth is 1.5 Meters (5 Feet)
Approach Angle is 40 Degrees
Departure Angle is 45 Degrees
Gradient Angle is 60 Degrees
Side Slope Angle is adjustable from 30 – 50%
Vertical Obstacle Height is 0.6+ Meter (24+ inches)
Trench Crossing Width is 1.8 Meters (6 Feet)
Turning Radius is 8 Meters (27 feet) curb to curb
Central Tire Inflation (CTI) is 2 Channel / Multi-Pressure
Hydraulic Winch Rating 30,000 Pounds- TBC
Engine is Caterpillar C9 rated 400 HP at 2,100 RPM with 1,100 LB-FT Torque at 1,400 RPM
Transmission is ZF Ecomat 6 Speed Electronically Controlled / 6 Forward & 1 Reverse
Transfer Case is Marmon-Harrington 2 Speed Electronically Controlled Gear Drive / PTO
All Wheel Steering with both Crab and Robo Modes
All Wheel Drive 6×6
Wheel Travel is adjustable up to 460 Millimeters (18+ inches)
Tires are Military 395/85 R20
Service Brakes are Air Hydraulic with ABS at each Wheel
Parking Brakes are Integral to Driveline / Spring Actuated / Hydraulically Released
Electrical System is 24VDC
Batteries are newer / 4 x 12V in Series-Parallel Arrangement
Alternator is 24V / rated at 260 Amps
Auto Charger is 230V with Auto-Eject Plug (same on the External Air Inlet)
Marion Body Fire Truck Cab SN 25466DB00 with variable Sirens and Lighting
Cab has three point restraint on all three seats (2 are fold down type seats)
Cab has two Piece Windshield
Cab has 13.5K/H (46,000 BTU) Heating System
Cab has 10.0K/H (34,000 BTU) Air Conditioning System
Hydraulic Multi-Functional Power Pack System
Price: $60,000
More info: Listing has ended. Click to search on eBay for similar Utility Truck (Affiliate link)
Seller's other items: *theblackraven*
Location: Nashville, Indiana, United States
